Continued thread
C.

For anyone who's curious, here's some crappy photos of the two boards I made. They're divided up differently than the original in mine, the "volume board" (a better description would be distortion and tone controls) includes the opamps 3a, 3b, 2a, and 2b, plus their surrounding components as well, in addition to everything inside the double lines. Even so, that board is a lot sparser than the "main" board.

#protoboard#breadboard#circuit
C.

This will be slightly #geeky, and probably only of interest to #electronics hobbyists and #guitar players. I happen to sit in the intersection of that particular #Venn diagram.

When I was a teenager, having only been playing guitar for a few years, I owned a guitar #effects pedal that went on to become legendary - the Boss HM-2 "Heavy Metal" #pedal. Its sound is still ubiquitous in metal.

I don't have it any more. I think I traded it for an analog chorus, which was a seriously expensive pedal back then. Although I have other #distortion effects, I've missed it a lot over the years.

Well, lots of hobbyists build their own effects. And the circuit schematics for many effects, particularly the classics, are available online. So like many others, I decided to build my own HM-2.

This image is the schematic for the #HM2. It's not the most complicated pedal, but it's a league above something like an Ibanez Tube Screamer. As far as active devices go, it's got 6 #opamps and 10 #transistors of various types, along with a bunch of diodes for multiple types and stages of clipping, and the usual jumble of capacitors and resistors. Oh, and four potentiometers.

1/x

#EffectPedal#HeavyMetal#pedals
